11KV Oil Immersed Power Distribution Transformer
  • 11KV Oil Immersed Power Distribution Transformer11KV Oil Immersed Power Distribution Transformer
  • 11KV Oil Immersed Power Distribution Transformer11KV Oil Immersed Power Distribution Transformer
  • 11KV Oil Immersed Power Distribution Transformer11KV Oil Immersed Power Distribution Transformer
  • 11KV Oil Immersed Power Distribution Transformer11KV Oil Immersed Power Distribution Transformer
  • 11KV Oil Immersed Power Distribution Transformer11KV Oil Immersed Power Distribution Transformer

11KV Oil Immersed Power Distribution Transformer

LuGao is a professional sales 11KV Oil Immersed Power Distribution Transformer Factory. Our unwavering dedication to excellence is evident in the delivery of high-quality products, customized to meet diverse requirements. Opt for Liu Gao for dependable solutions and profound expertise in the dynamic power industry.

Send Inquiry

Product Description

Lu Gao is a 11KV Oil Immersed Power Distribution Transformer Suppliers, our oil immersed transformers conform to Standards IEC. Its core is made of quality cold-rolled silicon sheet and is of a full-miter non-puncture structure and its coil is made of quality

oxygen-free copper.It adopts radiator oil tank of corrugated shteet type or expansion type.


As it doesn't need oil conservator, the height of oil-immersed transformer is reduced, and as the transformer oil doesn't contract with air, the oil ageing is retarded, thus prolonging the service life of oil-immersed transformer.


This product is widely used in urban power grid reconstruction, residential district, factory, high-rise building, mining factory, hotel, shopping mall, airport, railway, oil field, wharf, highway and other outdoor places.

11KV Oil Immersed Power Distribution Transformer Operating Environment

1. Highest ambient temperature: +40℃

2. Lowest ambient temperature: -25℃

3. Elevation: below 1000 meters

4. Highest monthly average relative humidity: 90% (at 20℃)

5. Installation location: suitable for installation in areas free from fire or explosion hazards, significant pollution, chemical corrosion, or excessive vibration, whether indoors or outdoors.

11KV Oil Immersed Power Distribution Transformer Characteristics

1. The oil-immersed transformer exhibits good heat emission and a substantial overload capacity. It can operate without a wind machine for an extended period at 130% overload, maintaining full load without compulsory wind cooling under IP45 conditions.


2. The oil-immersed transformer ensures perfect safety and resistance to fire, capable of withstanding combustion for a prolonged period at 800ºC without emitting smoke.


3. With strong resistance to thermal shock, the oil-immersed transformer can be loaded immediately at -50ºC.


4. The oil-immersed transformer features complete waterproofing and airproofing to enhance its durability.


5. Ensuring no partial discharge, the oil-immersed transformer maintains a high level of operational integrity.


6. With good hydrophobicity and resistance to alkaline cauterization and fundamental influence, the oil-immersed transformer proves to be reliable in diverse environmental conditions.


7. The oil-immersed transformer is environmentally friendly, producing low noise, no deleterious gases, and is easy to decompose.

11KV Oil Immersed Power Distribution Transformer Specification

Technical Data of 10kV S11, S11-M Series Distribution Transformer
Rated Capacity Voltage Group(kV) Connection Method Loss (kW) No-load current Impedance Voltage Weight (kg) (mm) Gauge
(L) (W) (H)
(kVA) HV LV No-load Load % % Machine Oil Gross Dimension Vertical Horizontal
10 0.065 0.4 3.5 90 55 220 650 450 880 400 350
20 0.08 0.52 3 140 60 270 720 490 950 400 350
30 0.1 0.63/0.6 2.3 185 70 330 750 490 970 450 340
50 0.13 0.91/0.87 2 260 80 430 770 550 1030 450 380
63 0.15 1.09/1.04 1.9 260 85 440 800 600 1040 450 380
80 0.18 1.31/1.25 1.9 320 95 520 790 600 1070 450 430
100 0.2 1.58/1.5 1.8 355 100 570 830 640 1050 550 450
125 11 0.24 1.89/1.8 1.7 425 115 675 1070 700 1150 550 470
160 10.5 0.28 2.31/2.2 1.6 510 130 790 1120 700 1220 550 520
200 10 0.4 Yyn0 0.34 2.73/2.6 1.5 550 145 850 1080 690 1160 550 520
250 6 0.69 Dyn11 0.4 3.2/3.05 1.4 630 165 985 1160 740 1190 650 550
315 6.3 0.48 3.83/3.65 1.4 755 190 1155 1230 800 1240 650 550
400 0.57 4.52/4.3 1.3 910 225 1405 1310 860 1250 650 550
500 0.68 5.41/5.15 1.2 1050 240 1600 1370 890 1350 750 600
630 0.81 6.2 1.1 4.5 1250 310 1945 1580 1060 1310 850 660
800 0.96 7.5 1 1540 365 2350 1640 1060 1500 850 660
1000 1.15 10.3 1 1690 405 2645 1720 1160 1540 850 660
1250 1.36 12 0.9 1965 560 3230 1790 1160 1740 850 660
1600 1.64 14.5 0.8 2355 650 3805 1830 1190 1850 850 700
2000 1.96 19.8 0.8 2570 615 4245 2190 1900 1950 820 820
2500 2.31 23 0.7 3130 810 5280 2180 1940 2250 1070 1070

Product Features

Factory Shoot

Packaging
