Product Description

As a professional high quality liu gao 33KV Oil Immersed Power Distribution Transformer manufacturer, you can rest assured to buy Oil Immersed Transformer from our factory and we will offer you the best after-sale service and timely delivery.

The performances of model Liugao S11-33KV series oil-immersed distribution transformes conform to Standards IEC. Its core is made of quality cold-rolled silicon sheet and is of a full-miter non-puncture structure and its coil is made of quality

oxygen-free copper.It adopts radiator oil tank of corrugated shteet type or expansion type.

As it doesn't need oil conservator, the height of transformer is reduced, and as the transformer oil doesn't contract with air, the oil ageing is retarded, thus prolonging the service life of transformer.

This oil-immersed transformers. widely used in urban power grid reconstruction, residential district, factory, high-rise building, mining factory, hotel, shopping mall, airport, railway, oil field, wharf, highway and other outdoor places.

33KV Oil Immersed Power Distribution Transformer Operating Environment

1. Highest ambient temperature: +40℃

2. Lowest ambient temperature: -25℃

3. Elevation: below 1000 meters

4. Highest monthly average relative humidity: 90% (at 20℃)

5. Installation location: suitable for installation in areas free from fire or explosion hazards, significant pollution, chemical corrosion, or excessive vibration, whether indoors or outdoors.

33KV Oil Immersed Power Distribution Transformer Characteristics

1.The oil-immersed transformer core is constructed using high-grade, imported cold-rolled silicon steel sheets, significantly reducing both no-load losses and currents. This also ensures a tight core binding for enhanced compactness and reduced noise levels.

2. The high and low voltage windings are meticulously wound with oxygen-free copper. For oil-immersed transformers with capacities of 500KVA and below, a double-layer, four-helix structure is employed for the low-voltage winding, while the high-voltage winding adopts a multi-layered cylinder configuration.

3. The oil-immersed transformer 's winding connections adhere to the Dyn11 standard, effectively minimizing the impact of harmonic waves on the power grid and enhancing overall power supply quality.

4. The oil-immersed transformer is designed with a fully-sealed structure, extending its operational lifespan and eliminating the need for suspended core usage and maintenance.

6. The measured noise level falls below established standards, ensuring a quieter and more efficient operation

33KV Oil Immersed Power Distribution Transformer Specification

Rated Capacity	Voltage Group(kV)		Connection Method	Loss (kW)		No-load current	Impedance Voltage	Weight (kg)			Dimension(mm)			Installation
Rated Capacity	Voltage Group(kV)		Connection Method	Loss (kW)		No-load current	Impedance Voltage	Weight (kg)			(LWH)			Size(mm)
(kVA)	HV	Tapping(%)		No-load	Load	%	%	Machine	Oil	Gross
SZ11-1600/35	35	±3%*2.5	Yd11	2.3	18.5	2.3	6.5/7/7.5/8	3600	1450	5050	2850	2050	2300	820 X 820
SZ11-2000/35	38.5			2.88	20.25	2		4300	1600	5900	3020	2250	2650	1070 X 1070
SZ11-2500/35				3.4	21.73	1.9		5200	1750	6950	3150	2280	2650	1070 X 1070
SZ11-3150/35				4.04	26.01	1.9		5950	1950	7900	3300	2350	2900	1070 X 1070
SZ11-4000/35				4.84	130.69	1.8		6850	2250	9100	3350	2650	3000	1070 X 1070
SZ11-5000/35				5.8	36	1.7		8400	2500	10900	3500	2650	3050	1070 X 1070
SZ11-6300/35				7.04	38.7	1.6		9850	2650	12500	3800	3150	3300	1070 X 1070
SZ11-8000/35			YNd11	9.84	42.75	1.5		12150	3350	15500	4200	3160	3400	1475 X 1475
SZ11-10000/35				11.6	50.58	1.4		14250	3750	18000	4500	3200	3500	1475 X 1475
SZ11-12500/35				13.68	59.85	1.4		19250	4250	23500	4800	3200	3600	1475 X 1475
SZ11-16000/35				16.46	74.02	1.3		19700	6300	26000	4900	3400	3700	1475 X 1475
SZ11-20000/35				19.46	87.14	1.2		25000	7500	32500	5000	35000	4000	1475 X 1475
