Liugao is a 380V Low Voltage Switchgear Fixed Switchgear Panel supplier The  Low voltage switchgear adopts common cabinet form, with frame of 8 MF local welding assembled cold bending section steel, with 20 mounting holes, and the general coefficient is high.

Considering the heat dissipation problems in Low voltage switchgear operation, there are several radiating slots on the upper and lower ends of the cabinet, the heat rises when the electrical components in the cabinet are heated , then it discharges through the top slot.                      And the cold air adds into the ark constantly through the bottom slot, which forms a natural air duct to achieve the goal of heat dissipation.

The Low voltage switchgear is designed according to the modern industrial product shape, using the golden ratio design method of the cabinet body and cut size of each part, making the cabinet beautiful and novel.

The Low voltage switchgear roof of the cabinet can be disassembled in case of need to make it convenient for the assembling and adjustment of the main bus- bar on the scene.                      There are four angle rings on the top of the cabinet, which is used for lifting and shipment.

The  Low voltage switchgear of the  protection grade is IP30, also it can be produced according to customer's requirements.

380V Low Voltage Switchgear Fixed Switchgear Panel Operating Environment

It is suitable for communities, shopping malls, schools, supermarkets, substations, industrial enterprises and other power users, with Ac 50Hz, rated voltage 400V, 690V, rated current 1000 ~ 3150A power distribution system, used for power conversion, distribution and control device of the power, lighting and power distribution equipment.

380V Low Voltage Switchgear Fixed Switchgear Panel Characteristics

The body of GGD AC LV fixed type switchgear adopts universal cabinet type. Framework is assembled with 8MF coldbending bar steel through part welding, Framework components and special mating elements are matched by bar steepointed manufactory for ensuring the precision and quality of cabinet. Components of universal cabinet is designed accordingto madule principle,and with20 modulus mounting hole and high universal coefficient.2. Completely in view of the heat rejection during cabinet running. Heat rejection slots of different quantities are installed inupper and underside both ends of cabinet.3. According to the requirements on mold design for modern industry products, adopting the method of golden meanratio to design cabinet outline and parting dimensions of each part,to make the whole cabinet beautiful and decent4. Cabinet gate is connected with framework with rotation axis type movable hinge. With convenient installation anddisassembly. One mount type rubber strip is set in edge fold of gate. Filer rod between gate and framework has certaincompression stroke when closing the gate. t can prevent gate from impacting cabinet directly and also advance the protectiongrade for gate.5. Connect the meter gate set with electrica! components with framework by multistrand soft copper wire.Connect themounting pieces inside the cabinet with tramework by knurled screws.the whole cabinct constructs complete carthinprotective circuit.6.Top cover of cabinet can be disassembled if necessary for convenience to the assembly and adjustment for main bus bar atsite Four squares ofcabinet are set with slinger for hoisting and shipping.7.Protection grade of cabinet: P30. User can choose within P20-IP40 according to environmental requirements.
